Marca: FERRTX
| Unidades de venta: | Piece/Pieces |
|---|---|
| Descargar: |
|
El Inductor de clase D de alta calidad HDA es un Inductor de potencia premium diseñado para sistemas de audio de alto rendimiento. Utilizando tecnología avanzada de Inductor Clase D, combina una construcción con blindaje magnético (para un ruido de radiación ultrabajo) con un manejo de corriente súper alto y una resistencia mínima para brindar una calidad de sonido impecable.
Optimizado para aplicaciones de Inductor de amplificador de clase D como amplificadores digitales y sistemas de audio para automóviles, este Inductor de potencia funciona de manera confiable entre -40 ℃ y +130 ℃ y cumple con los estándares RoHS.
Serie en esta familia.
| Product Series | Inductance(µH)±20% | DCR Max(mΩ) | Isat Max(A) | Irms Max(A) | D(mm) |
| HDA1010 | 10-15 | 18-23 | 4.3-7.5 | 4.0-5.5 | 0.4-1.2 |
| HDA1010AG | 10-33 | 20.5 | 2.0-7.5 | 4.5 | 0.6 |
| HDA1315B | 10-33 | 5.6-16 | 3.8-7.0 | 5.5-8.5 | 0.33-0.5 |
| HDA1315E | 10-33 | 10-12 | 3.5-11.0 | 7.0-7.5 | - |
| HDA1416A | 10-33 | 15-28 | 5.5-11.5 | 5.0-7.0 | 0.65-0.8 |
| HDA1416B | 10-47 | 6.5-20 | 6.0-9.0 | 5.0-8.0 | 1.8 |
| HDA1416C | 10-27 | 12-20 | 9.0-15.0 | 5.0-7.0 | 1.8 |
| HDA1416D | 10-33 | 15-28 | 5.5-11.5 | 5.0-7.0 | 0.65-0.8 |
| HDA1516 | 10-33 | 11-22 | 5.5-11.0 | 4.5-7.0 | 0.6-0.8 |
| HDA1521A | 10-33 | 11-33 | 8.5-14.0 | 5.0-7.7 | 0.7-0.9 |
| HDA1719 | 10-47 | 7.0-34 | 8.0-22.0 | 5.0-12.0 | - |
| HDA1931A | 10-33 | 4.0-8.2 | 25.0-50.0 | 10.0-18.0 | - |
| HDA2023A | 10-33 | 8.0 | 12-36 | 10-12 | - |
| HDA2023B | 10-33 | 8.3-12.0 | 11.0-31.5 | 8.0-9.1 | 1.1-1.2 |
| HDA3718H | 10-33 | - | - | - | 1.8-2.4 |
| HDAS0910 | 10-22 | 22-52 | 3.2-5.0 | 2.5-3.9 | - |
| HDAS1010 | 10-22 | 18-38 | 4.3-7.1 | 3.5-4.2 | - |
