Marca: Ferritas
| Unidades de venta: | Piece/Pieces |
|---|---|
| Descargar: |
|
La serie Inductor de alto voltaje HCB ofrece un rendimiento de núcleo de ferrita diseñado para Topologías de inductor acoplado de alto voltaje . Como Solución de inductor de potencia , combina:
・ Manejo de corriente de grado de alto voltaje (14a-35a)
・ Reducción de pérdida de núcleo
・ Inductor de energía Fiabilidad en -40 ℃ a +125 ℃ Rangos de operación/almacenamiento
Diseño eléctrico
・ 22NH - 1220NH Inductancia (personalizable para Inductor de alto voltaje HCB)
・ Material de ferrita de inductor acoplado de alto voltaje
Durabilidad
・ ・ UL VW-1 Cumplante Inductor de potencia Tubo de contracción
・ Inductor de alto voltaje Resiliencia térmica de grado de servidor de HCB
Electrónica
・ Módulos VRM utilizando matrices de inductor de potencia
・ Tarjetas gráficas con Inductor de alto voltaje Entrega de energía HCB
Infraestructura
・ Reguladores múltiples ( Inductor acoplado de alto voltaje Topologías)
・ Sistemas de batería ( Control de carga/descarga de energía mejorada)
Serie de esta familia
| Product Series | Inductance(µH) | IDC(A) | Length (mm) | Width (mm) | Height (mm) |
| HCB0404 0505 | 22-100 | 19-30 | 4.0-5.0 | 4.0-5.0 | 3.0-4.8 |
| HCB0703 | 80-150 | 13-27 | 7.35 | 6.6 | 3.1 |
| HCB0705 | 72-226 | 16-43 | 7.0 | 7.0 | 4.95 |
| HCB0805 | 32-200 | 16-65 | 7.62 | 7.62 | 4.96 |
| HCB0906 | 100-300 | 27.5-51 | 9.6 | 6.4 | 8.0 |
| HCB1005 | 80-220 | 26-53 | 10.2 | 7.0 | 4.95 |
| HCB1007 | 115-470 | 19-61 | 10.5 | 8.0 | 7.0 |
| HCB1008 | 120-220 | 47-68 | 10.2 | 8.0 | 8.0 |
| HCB1107 | 120-510 | 14.5-55 | 11.2 | 7.2 | 7.2-7.5 |
| HCB1208 | 150-250 | 44-50 | 11.8 | 8.1 | 8.0 |
| HCB1211 | 230-540 | 26-40 | 11.7 | 11.5 | 9.2 |
| HCB1313 | 220-500 | 28-40 | 13.46-13.5 | 13.0-13.2 | 5.3-8.0 |
| HCB1413 | 300-680 | 24-45 | 14.5 | 13.3 | 9.5 |
| HCB040404R32 | 55-100 | 17-19 | 4.0 | 4.0 | 4.0 |
| HCB070705R32 | 100-180 | 28-50 | 7.0 | 6.8 | 4.0 |
| HCB100612R125 | 70-330 | 40-77 | 12.0 | 10.0 | 6.0 |
| HCB100709R18 | 100-400 | 30-70 | 10.0 | 7.0 | 9.0 |
| HCB100808AR18 | 120-400 | 26-70 | 10.0 | 8.0 | 8.0 |
| HCB100808R18 | 100-320 | 45-74 | 10.6 | 8.0 | 8.0-8.2 |
| HCB100875R29 | 100-370 | 30-56 | 10.2 | 8.0 | 7.5 |
| HCB121109R30 | 150-500 | 32-55 | 11.5 | 11.0 | 9.0 |
