Marca: FERRTX
| Unidades de venta: | Piece/Pieces |
|---|---|
| Descargar: |
|
transporte: Ocean,Land,Air,Express
Lugar de origen: Porcelana
Apoyo sobre: 2~8weeks
Certificados : RoHS/ISO/UL/CE/IATF16949/CNAS
Hafen: Xi'an,Shanghai
Tipo de Pago: L/C,T/T
Diseñados con tecnología avanzada de núcleos de polvo de aleación, los núcleos Sendust de la serie SDR-T ofrecen una eficiencia incomparable en diseños compactos. Esta solución magnética consigue:
| Product Series | L(µH) | Test Freq(KHz) | DCR Max(Ω) | IDC Max(A) |
| SDR0703T | 1.0-1000 | 100 | 0.02-6.2 | 0.15-3.6 |
| SDR0704T | 10-1000 | 100 | 0.12-6.22 | 0.17-1.5 |
| SDR1030T | 2.7-1000 | 0.796-7.96 | 0.028-4.7 | 0.2-3.0 |
| SDR1045T | 2.7-1000 | 0.252-7.96 | 0.026-4.7 | 0.38-4.8 |
| SDR1305T | 2.5-1000 | 0.252-7.96 | 0.0098-2.35 | 0.46-7.2 |
| SDR1308T | 10-1200 | 0.252-2.52 | 0.036-1.92 | 0.38-4.05 |
| SDR7030T | 1.0-1000 | 0.796-7.96 | 0.022-6.2 | 0.15-3.0 |
| SDR7045T | 1.0-1000 | 0.252-7.96 | 0.022-4.0 | 0.22-3.8 |
